Cardputer uLisp Machine

#1

The Cardputer uLisp Machine is a handheld Lisp computer based on an M5Stack Cardputer Kit:

Cardputer
Cardputer.jpg1120x740 117 KB

The M5Stack Cardputer is a card-sized portable computer based on the ESP32-S3, available for about £30/$30. It has a 240x135 colour TFT display that gives a scrolling display of up to 16 lines of 40 characters, an integrated 56-key keyboard, and an SD card socket.

The Cardputer is contained in a fairly rugged case, and includes a 120 mAh rechargeable battery on the main board and a 1400 mAh LiPo cell in the backpack. These can be charged from the USB port.

The firmware is based on the ESP version of the latest 4.7 release of uLisp, with several enhancements to support the Cardputer. For more details see:

Cardputer uLisp Machine

Acknowledgements to @hasn0life who did the initial work on this.

#2

It’s a great little device for the size, price, and capabilities – M5Stack, like LilyGo, is really coming up with some cool loadouts and prototyping devices of late. It’s got a nicer keyboard for programming than the T-Deck, too, though suspect T-Deck’s might last longer.

My main regret is that it lacks PSRAM, even a 2MB PSRAM would have greatly boosted its capabilities and flexibility. A slightly larger screen would also have been nice, but those get expensive in cost and power really quickly – maybe a Sharp Memory display instead? Oh well, guess I’ll hope for a Cardputer-Plus or -Pro.

#3

M5Stack released Cardputer v1.1.

#4

If anyone gets one can they report back about what’s better about it, and to what extent it’s an improvement over the original one?

#5

It would be interesting to know whether the Cardputer 1.1 addresses the serial buffer overflow issue.

#6

I would like to see the LCD panel could be upgraded to a double width size, which would be more friendly to play with uLisp on it.

@amoroso I just ordered the v1.1 version, I’ll test it once I receive it and let you known the result. Another things I want to do is try to compile the uLisp with the ESP32 SDK instead of the Arduino IDE.
